Display

Design of display

19" TFT touch

19 in

Screen diagonal

Resolution (pixels)

●    Horizontal image resolution

●    Vertical image resolution

1 280 pixel

1 024 pixel

Backlighting

●    MTBF backlighting (at 25 °C)

50 000 h

Control elements

Input device

●    Integrated mouse cursor control

●    Mouse, at front

No

No

Keyboard fonts

●    Function keys

— Number of function keys

●    alphanumeric keyboard

No 0

No

Touch operation

●    Design as touch screen

Yes

Installation type/mounting

central design

Yes

No 45°

distributed design

maximum permissible installation angle +/-

Supply voltage

Type of supply voltage

110/230 V AC or 24 V DC

Power loss

In full configuration

24 V DC: max. 80 W (incl. USB interfaces)

Processor

Processor type

Intel Celeron M 1.2 GHz, Intel Core2Solo 1.2 GHz, Intel Core2Duo 1.86 GHz

Drives

Optical drives

Optional: DVD±R±RW combi drive; on rear, can be operated from side

3.5" SATA hard disk ≥ 80 GB, vibration-resistant mounting

Hard disk

Memory

Type of memory

DDR3-SDRAM 512 MB

4 096 Mbyte; At least 3.2 GB can be used

Main memory

Capacity of main memory, max.

Data areas and their retentivity

Retentive data area (incl. timers, counters, flags), max.

2 048 kbyte; 128 KB can be stored in the buffer time

Hardware configuration

Slots

●    free slots

●    Number of PCI slots

●    Number of compact flash slots

1x CF card slot, externally accessible, 1x PCI slot in device interior, 1x SSD slot 1

1

Interfaces

PROFIBUS/MPI

1x CP 5611 comptable

1x on front, 4x on reverse, USB 2.0 (3x 500 mA) USB / USB

COM1: 1x V.24 (RS 232) 0

No No

USB port

Connection for keyboard/mouse

serial interface

parallel interface

Multimedia

●    Audio In/Out

●    Microphone In

Video interfaces

●    Graphics interface

DVI-I: VGA / DVI combined

Industrial Ethernet

●    Industrial Ethernet interface

PROFIBUS version, onboard 2 x: PROFINET version, onboard 1 x:

10/100/1000 Mbit/s, RJ45, no plug-in card necessary.

— 100 Mbps

Yes

— 1000 Mbps

Yes

Protocols

Protocols (Ethernet)

●    TCP/IP

Yes

Integrated Functions

Monitoring functions

●    Temperature monitoring

●    Watchdog

●    Status LEDs

Yes Yes

No

Degree and class of protection

IP (at the front)

IP65

Standards, approvals, certificates

CE mark

Yes

CE, EN 61000-6-4; CISPR 22:2004 Class A; FCC Class A

EMC

Use in hazardous areas

●    FM Class I Division 2

No

Marine approval

●    Germanischer Lloyd (GL)

No

●    American Bureau of Shipping (ABS)

No

●    Bureau Veritas (BV)

No

●    Det Norske Veritas (DNV)

No

●    Lloyds Register of Shipping (LRS)

No

●    Polski Rejestr Statkow (PRS)

No

Ambient conditions

Ambient temperature during operation

●    min.

0 °C

●    max.

50 °C

Relative humidity

●    Relative humidity

Tested according to IEC 60068-2-78, IEC 60068-2-30: Operation: 5% to 85% at

30 °C (no condensation) Storage: 5% to 95% at 25 °C (no condensation)

Vibrations

●    Vibration resistance during operation acc. to IEC 60068- 2-6

Mech. environmental conditions tested in acc. with IEC 60068-2-6 Vibration: in operation with CompactFlash Card and SSD: 10 Hz to 58 Hz: 0.075 mm, 58 Hz to 500 Hz: 9.8 m/s²; in operation with HDD: 10 Hz to 58 Hz: 0.0375 mm, 58 Hz

to 500 Hz: 4.9 m/s²

Shock testing

●    Shock load during operation

Tested according to DIN IEC 60068-2-7: 50 m/s² (5 g), 30 ms

Operating systems

pre-installed operating system

Windows XP Embedded and Win XP Prof.

Additional info on operating system

WIN XPe: GER/ENG WIN XP Prof: MUI Language: GER, ENG, IT, FR, SP,

KOR, CHN (traditional), CHN (simplified), JPN

without operating system

Yes

pre-installed operating system

●    Windows XP Professional

Yes; Only with SSD or HDD
